Movicon X. The first and only Scada/HMI
platform to be completely based on XML and Web
Services, from WinXP to WinCE
Movicon X™ is the tenth
evolutional version of Movicon, the latest generation software for supervision, monitoring,
data acquisition and process control (Scada/HMI). Simple-to-use, high
performances and scalability are its dominant tools of success.
Movicon X™ is an
integrated and powerful work platform, purposely designed to make your work easier,
faster and more pleasurable to do. All the basic problems in developing
automation applications have been resolved by integrating all you will
ever need into a one enviroment only, ready and waiting
at your finger tips.
The object programming
technology allows you to create sophisticated supervision and control solutions
in just a few minutes with immediate hardware device connections.
.
Movicon X™ introduces
the most innovative technology into industrial supervision systems to guarantee
the highest efficiency, openness and scalability, by renewing the whole
supervision concept in "open Web architecture".
The new version of
Movicon is completely based on the XML technology, and includes functions
especially designed to
bring the openness and
security standards up to factory levels, breaking down those annoying barriers
and obstacles that get in the way of distributing data
smoothly.
The technologies on which Movicon X is based guarantee
the user the use of a revolutionized product without
having to compromise architecture and performances,
while guaranteeing extreme simplicity of use and
therefore making it quicker to develop at the same
time.
There
are many other innovative
features that make Movicon X the most modern Scada/HMI platform on the world market
today.
The advantages you get when using Movicon X are:
Just one only development environment, from
WinXP to WinCE.
Unmatched openness thanks to the XML
structure
Unmatched Networking based on the SOAP
and Web Services
The Movicon projects are built with XML files to
ensure openness, transparency, and high velocity. Every
thing has been based on XML doing away with
traditional import/export commands, as each single
object or resource can now be dragged and dropped into
other applications in XML format.
Complete object programming with a comfortable and
extremely userfriendly working environment. The
graphic libraries are simple, complete and
customizable. The Power Template technology allows
the more "complex" objects to be created and re-used.
Although based on Openness, the projects can also be
"cripted" and protected, and are totally
CFR21 Part
11 ready.
The innovative graphics are based on the SVG
technology, the most highest performing vectorial
technology of all those currently
available today.
The drivers include extreme performance and
innovative connectivity technology with the option
to remote connect to devices via modem.
The importers allow the PLC's Tag database to be
used for importing predefined variables to projects
in order to avoid errors being made and to reduce
time spent in developing project. In this way
the variables will be already addressed to the PLC
for the drivers.
Wizards
can be used to auto-create projects, which can also
be done with macros which can be set to allow
users to auto-create entire projects in XML
format.
The historical events and alarms management include
diagnostic functions according to the ISA normatives,
with event notifications via SMS, Voice, Email.
The Data Loggers are very efficient and very high
performing with open databases due to the automatic
and transparent integration of the ODBC
technology (MsSQL Server, Oracle...) and the
exclusive IMDB technology (InMemory DB in
XML).
Trends are based on the vectorial technology and
the historicals support ODBC or IMDB. The
wide-rangiing versetility makes the Trends extremely
powerful in analysing and representing
data. Additional new functions allow
further enhancement and increased
performances.
The connectivity technologies permit information to
be distributed, without obstacles getting in the
way, with complete
transparency and efficiency. TCP-IP, UDP and Http
are supported along with the Web Services, dynamic exchanging via XML and ODBC.
Movicon includes the new OPC XML DA technology, in
addition to the OPC DA Client and Server technology.
The logic guarantees the maximum freedom to
customse using the integrated VBA languages (Visual Basic for
Application comp.) with complete multithreading and
debugging, and with the integrated SoftLogic (AEWL
language similar to Simatic Step7) and visual
Synapsis language.
The Web Client solutions offer access
to and the viewing of projects via web by using any browser
with any operating system which has been made
possible by the Java technology
support. The JavaPhones technology is also supported
for accessing servers with mobile phones.
Complete project Debugger with simulation, forcing,
analysing errors, break-points, traceability,
backup. Remote Project Debugging can now be
done in net, indispensable for WinCE project
debuggin for example.
All Progea software solutions had been desgined to
offer you:
Easy-to-use
Openness
Standards
Flexibility
Importing and re-use
Connectivity
Security
Reliability
Movicon X is a Progea
registered trademark and all rights are reserved.
Movicon is certified as
"Designed for Windows XP" by Microsoft and is tested
and certified by OPC Foundation.
