Panel-PLC 0035V
Part No: PC350V-0-03
.
Insevis 3.5" HMI Panel with S7-300 PLC CPU integrated

S7-Panel-PLC 7
��Expand using Insevis Remote I/O rack on CanBus, or Helmholz I/O on S7-300 I/O or TB20 I/O

Programmed with STEP7, TIA Portal from Siemens, or WinPLC7 from Automation Warehouse.

HMI software VisuStage is provided for free for small projects and small cost for large projects.

512kB work- and 4MB visualisation memory the INSEVIS-Panel-PLC with 3.5inch, 320x240 Pixel 4:3 format.
The brilliant display is an eye catcher, large library of graphical objects make this panel a powerful but easy to create visualisation.
The integrated CPU-V includes onboard interfaces, Ethernet (S7-communication, TCP, UDP), Modbus (TCP, RTU), CAN (CANopen and Layer2), RS232 and RS485 (free ASCII) included.


Supplied with Spring Terminal Front Connector

Resource Download
Manual
http://www.automationwarehouse.com.au/
manuals/insevis/Manual_PanelHMI.pdf

VisuStage - Creating a Free SCADA type visualisation
http://www.automationwarehouse.com.au/
manuals/insevis/Create_free_remote_visualisation.mp4

First Steps with STEP7 from Siemens
http://www.automationwarehouse.com.au/
manuals/insevis/First_Steps.pdf

First Steps with WinPLC7
http://www.automationwarehouse.com.au/
manuals/insevis/First_Steps_WinPLC7.pdf

How to set the IP address from factory STEP7
http://www.automationwarehouse.com.au/
manuals/insevis/Set_IP_Address_STEP7.mp4

How to set the IP address from factory TIA Portal V14
http://www.automationwarehouse.com.au/
manuals/insevis/Set_IP_Address_TIA_V14.mp4


Alternative to Siemens:
6ES7 315-2EH14
