AI 4xV 12Bit
Part No: 600-252-4AD01
.
Analog input module - AI 4 x V, ±10 V, 0-10 V, 1-5 V, 12 Bit

Characteristics
• 4 analog inputs for measuring voltage, electrically isolated from the backplane bus
• 4 process input words
• Measuring ranges: 0-10 V, 1-5 V, ±10 V, ±5 V, ±2.5 V, individually configurable for each channel
• Measurement resolution: 12 bits + sign
• Diagnostic messages
• Wire break detection (for 1-5 V)
• Limit value alarms for each channel
• A bi-color LED (blue/red) indicates the module’s operating status and any malfunctions

Parameters for the module
• Diagnostic alarm: On | Off
• Overflow / underflow diagnosis: On | Off
• Representation values: SIMATIC* S7 | SIMATIC* S5

Parameters for each channel
• Wire break detection (for 1-5 V only): On | Off
• Interference frequency suppression: None | 10 Hz | 50 Hz | 60 Hz | 400 Hz
• Measuring ranges: Disabled | 0-10 V | 1-5 V | ±10 V | ±5 V | ±2.5 V
• Limit value alarms enabled: On | Off
• Upper/lower limit: 16-bit analog value (±27648)
