SPEED7 314SB DPM -256KB
Part No: VIPA 314-2AG23
.
CPU 314SB/DPM – SPEED7 Technology

Programmed by STEP7 or TIA Portal from Siemens or WinPLC7 from VIPA
DC 24V
256KByte memory, expandable up to 512KByte work memory,(50% program + 50% data)
MPI interface, 187.5 to 12Mb!
MMC slot,
real time clock,
8192/8192byte I/O address area
512 timers (IEC timers unlimited)
512 Counters (IEC Counters unlimited)
8192 flag byte
Firmware upgrade via MMC
Ethernet interface for PG/OP communication, up to 4 connections
Profibus-DP master, 12MBaud, up to 126 slaves,
The SPEED7 CPU's from VIPA are the fastest PLC in the world, more than 10x faster than the Siemens S7-400 CPU's the VIPA SPEED7 can handle the biggest applications. The memory is not fixed in size, it is expandable by purchasing a MMC memory upgrade, so your plant cost life cycle is reduced.

Click for Features Matrix
