CPU 214PG 96K (STEP7)
Part No: VIPA 214-2BE03
.
CPU 214, 96kByte work Memory, Intern. Flash EPROM
TCP/IP Port for SCADA, HMI Panels and PG – Programming with STEP7 or WinPLC7
TCP - 8 Passive connections max
TCP/IP port Programmable with STEP7 NetPro from Siemens.
MMC-Slot. Clock
144K Load Memory
No MMC required
Datablocks - 2047
Function Blocks - 1024
Function Charts - 1024
Scan Time Bit - 0.18micro sec
S7 Counters - 256
S7 Timers - 256
IEC Timers - Yes
Flags - 8192 bits
I/O address - 1kByte / 1kByte
Process image - 128 Bytes
Modules per line - 32
Modules total (local) - 32
MPI Port
DP Port - optional IM208
Programmable with STEP®7 from Siemens
