Part Number:
VIPA 013-CCF0R00
Description:
CPU 013c - SPEED7 Technology
Power supply: DC 24V
Onboard I/O, 16DI, 12DQ, 2 x AI (4 x 100kHz, 2 x PWM up to 20kHz)
Working memory integrated: 64kByte (50% program / 50% data)
Working memory expandable up to: 128kByte (50% program / 50% data)
Interface 1: RJ45: TCP/IP PG/OP-communication (Switch)
Interface 2: RJ45: TCP/IP PG/OP-communication (Switch)
Interface 3: RS485 (isolated): MPI, USS-Master, ASCII, ETX/STX, 3964R, Modbus-Master /-Slave (switchable), optional Profibus Slave
SD card slot with locking mechanism
Expandable up to 64 SLIO modules pluggable
Programmable via SPEED7 Studio, SIMATIC Manager and TIA Portal
